1" Bore Bottom Tapped Pillow Block

SKU: Build System: Actobotics
$11.99 $4.80
(You save $7.19)

This 1" bore Bottom Tapped Pillow Block has threaded holes on the feet in order to easily mount to a plate, bracket or channel. The height from base to the center of the bearing is 0.75" so that, when installed on the Actobotics pattern, you’re able to easily mesh 32 or 48 pitch gears. As with all pillow blocks, the included bearing is pressed in so you don’t have to worry about it walking out during use.



Material Aluminum Housing, High-Carbon Steel Bearing
Weight 0.56 oz (16g)
Static Load 212 lbs
Max RPM 21,000
Bearing ID 1.00"
Dynamic Load 485 lbs
