32 Pitch, 80 Tooth (.50" Bore) Aluminum Hub Gear
SKU:
Build System: Actobotics
This 80 tooth hub gear is a popular choice, paired with a 16 tooth pinion gear, to create a 5:1 ratio between holes spaced 1.5” apart. The ½” bore and 0.77” Actobotics hub pattern means you can attach a hub with the bore of your choice. The gear has a dished side and a flat side so that you can adjust the position of your gear by flipping it over.
Downloads
Specs
| # of teeth | 80T |
|---|---|
| Weight | 0.92 oz (26g) |
| Material | Aluminum |
| Finish | Clear Anodized |
