HSB-9370TH Servo

  • HSB-9370TH top view
  • HSB-9370TH in box
  • HSB-9370TH side view
  • HSB-9370TH back view
  • HSB-9370TH with quarter for scale
  • HSB-9370TH included hardware
  • A Power Absorbing Device (PAD) is included with this servo
1 of 8

Be the first to review this product

Price
$179.99
$179.99 - $209.99
Sign up for Price Alert
Part
39370
39370
Status
In stock

* Required Fields

Price
$179.99
$179.99 - $209.99
Sign up for Price Alert
This Product? Share It!

Details

With ultra-efficient Neu brushless motors, titanium gear trains, low current consumption, and constant output power, the HSB-93XX series of servos is the perfect match for the most discriminating pilots and racers.
SPECS

Special Features:

- Constant torque output: Revolutionary circuit and motor designs allow the HSB-9XXX Series servos to maintain their speed in a more consistent manner, regardless of load.
- Hybrid MPD 1st Gear: Unique ultra-durable Metal/Plastic/duralumin hybrid first gear prevents inadvertent electrical noise from affecting other components within your aircraft or vehicle
- Custom NeuMotor: Designed by Steve Neu exclusively for the HSB-9XXX Series, these high performance, brushless motors provide long-standing durability and performance.

Brushless Advantages:

- At least FIVE TIMES longer-lasting than brushed servos.
- 30% faster response times.
- Greater resistance to jolts and vibration.
- Smoother operation.
- Same power consumption as brushed digital servos.
- Same compact case size as standard servos.
- Exceptionally durable geartrain.
- Smooth dual ball bearings

PLEASE NOTE: While compatible with most radio control devices, the regenerative braking feature of the HSB-93XX series servos may cause a problem if the device cannot accept a backflow of current. The types of devices that cannot accept this backflow are: Voltage Regulators, Power Safe Receivers and certain BEC circuits whether stand alone or integrated within an Electronic Speed Control. Check with the manufacturer or the Hitec website for a list of compatible models. If your device cannot accept a current backflow, then you must install a PAD (Power Absorbing Device - Hitec PN# 55756) as described in the manual. A PAD is included with every Hitec brushless servo.

Dimensions 1.57” x 0.79” x 1.50” (40 x 20 x 38mm)
Product Weight 2.4oz (68g)
Output Shaft Style 25 tooth (H25T) spline
Voltage Range 6.0V - 7.4V
No-Load Speed (6.0V) 0.12 sec/60°
No-Load Speed (7.4V) 0.10 sec/60°
Stall Torque (6.0V) 347 oz/in. (25 kg.cm)
Stall Torque (7.4V) 347 oz/in. (25 kg.cm)
Max PWM Signal Range (Standard) 700-2300μsec
Travel per µs (out of box) .075°/μsec
Max Travel (out of box) 120°
Pulse Amplitude 3-5V
Operating Temperature -20°C to +60°C
Continuous Rotation Modifiable Yes
Direction w/ Increasing PWM Signal Clockwise
Deadband Width 2µs
Motor Type Brushless
Feedback Style 5KΩ Potentiometer
Output Shaft Support Dual Ball Bearings
Gear Type Straight Cut Spur
Gear Material Titanium (Hybrid MPD 1st Gear)
Wire Length 11.81" (300mm)
Wire Gauge 20AWG
