Mini V-Wheel Spacer (4 pack)

Sold in packs of four.
Sold in packs of four.
  • Sold in packs of four.
1 of 9

Be the first to review this product

Part
633177
633177
Status
In stock
This Product? Share It!

Details

Mini V-Wheel Spacers are intended to be used with the Actobotics Mini V-Wheels.  The spacers have an OD of 5mm so that the bearing of the Mini V-Wheel slides over; the length is the same as the overall width of the Mini V-Wheel.  The spacer acts as a collar to keep pressure from being applied to the bearings within the Mini V-Wheels when a fastener is tightened down to hold the assembly together.  These spacers can be used in conjunction with our 6-32 standoffs if you want to create an overall height other than what we offer in the Mini V-Wheel Standoffs. They can be paired with a single 0.250" OD spacer so that a long screw can pass through both spacers and into a threaded hole or they can be used in-between multiple 0.250" OD spacers to create a 'Mini V-Wheel Sandwich'.  Check out the 'Build Ideas' images for some other great usage illustrations.  These spacers are sold in packs of 4.

SPECS

Material Aluminum
Inside Diameter 0.138"
Outside Diameter 5mm
