SA1230SGP Coreless Digital Servo
SKU:
The Savox SA-1230SG Monster Torque Steel-Gear digital servo is the servo that is ideal for those requiring extra torque, but not using high voltage as a power source.
How Far Will This Servo Rotate?
The answer to this question is partially dependent on what you are using to control the servo.
Click for a quick video explanation.
With an Average Radio System:
102°
Your average transmitter and receiver will output a relatively narrow PWM signal range.
Radio System + Travel Tuner:
160°
Adding a Servo Travel Tuner to your radio system setup will allow you to achieve wide PWM signal ranges.
Wide Signal Controllers:
160°
Controllers such as the Actobotics® Servo Controller, Arduinos, and Raspberry Pi servo hats can usually send a wide signal.
Tech Tips
Specs
| Output Shaft Style | H25T Spline |
|---|---|
| Voltage Range | 4.8V ~ 6.0V |
| No-Load Speed (4.8V) | 0.20 sec/60° |
| No-Load Speed (6.0V) | 0.16 sec/60° |
| Stall Torque (4.8V) | 416.6 oz-in (30.0 kg.cm) |
| Stall Torque (6.0V) | 499.9 oz-in (36.0 kg.cm) |
| Max PWM Signal Range | 800-2200μsec |
| Pulse Amplitude | 3-5V |
| Operating Temperature | -10°C to 50°C |
| Current Drain - idle (4.8V) | 5mA |
| Current Drain - idle (6.0V) | 5mA |
| Current Drain - no-load (4.8V) | 180mA |
| Current Drain - no-load (6V) | 250mA |
| Current Drain - stall (4.8V) | 4200mA (4.2A) |
| Current Drain - stall (6V) | 5300mA (5.3A) |
| Direction w/ Increasing PWM Signal | Counterclockwise |
| Motor Type | Coreless |
| Output Shaft Support | Dual Ball Bearings |
| Gear Material | Steel |
| Wire Length | 7.0" (177.8mm) |
| Weight | 2.8oz (79g) |
| Wire Gauge | 22 AWG |
| Servo Size | Standard |
| Max Rotation | 160° |
| Travel per µs | 0.114°/µsec |
| Previous SKU | SA1230SG |
