1/4" Bore Bottom Tapped Pillow Block

SKU: Build System: Actobotics

DISCONTINUED This product has been discontinued.

Consider This Alternative:

While its mounting holes are goBILDA® (metric) instead of Actobotics® (imperial), please consider this otherwise similar alternative.

1-Side, 2-Post Pillow Block (1/4" Bore)


1-Side, 2-Post Pillow Block (1/4" Bore)

Currently Sold Out

This ¼" Bottom Tapped Pillow Block has threaded holes on the feet in order to easily mount to a plate, bracket or channel.  The height from base to the center of the bearing is 0.75" so that, when installed on the Actobotics pattern, you’re able to easily mesh 32 or 48 pitch gears.  As with all pillow blocks, the included bearing is pressed in so you don’t have to worry about it walking out during use.



Material Aluminum Housing, High-Carbon Steel Bearing
Weight 0.34 oz (9.7g)
Static Load 84 lbs
Max RPM 50,000
Bearing ID 0.250"
Dynamic Load 186 lbs
