Stalling this gearmotor could cause gear damage.
Output Shaft Style | D-shaft |
---|---|
Motor Type | Brushed DC |
Output Shaft Support | Bushing |
Gear Material | Brass Primary, Plastic Secondary Steel on Subsequent Stages |
Weight | 225g (7.94 oz) |
Voltage (Nominal) | 12V |
Voltage Range (Recommended) | 3V -12V |
Speed (No Load @ 12VDC) | 45 rpm |
Current (No Load @ 12VDC) | 0.10A |
Current (Stall @ 12VDC) | 2.4A |
Torque (Stall @ 12VDC) | 208 oz-in (15 kgf-cm) |
Gearbox Style | Straight Cut Spur |
Connector Type | Male Spade Terminal |
Motor Brush Type | Graphite |
Gear Ratio | 100:1 |
