HS-425BB-Clockwise (stock)-Stock Rotation
SKU:
The HS-425BB is offered with dual ball bearings, impact resin gears and high performance circuitry. As one of Hitec's longest running production servos, it has proven to be a durable and dependable product year after year.
How Far Will This Servo Rotate?
The answer to this question is partially dependent on what you are using to control the servo.
Click for a quick video explanation.
With an Average Radio System:
86°
Your average transmitter and receiver will output a relatively narrow PWM signal range.
Radio System + Travel Tuner:
188°
Adding a Servo Travel Tuner to your radio system setup will allow you to achieve wide PWM signal ranges.
Wide Signal Controllers:
188°
Controllers such as the Servo Commander, Arduinos, and Raspberry Pi servo hats can usually send a wide signal.
Tech Tips
Specs
| Output Shaft Style | C24T Spline |
|---|---|
| Voltage Range | 4.8V - 6.0V |
| No-Load Speed (4.8V) | 0.21sec/60° |
| No-Load Speed (6.0V) | 0.16sec/60° |
| Stall Torque (4.8V) | 45.82 oz-in (3.3 kg.cm) |
| Stall Torque (6.0V) | 56.93 oz-in (4.1 kg.cm) |
| Max PWM Signal Range | 553-2520μsec |
| Travel per µs (Stock) | .096°/μsec |
| Max Rotation (Stock) | 188° |
| Pulse Amplitude | 3-5V |
| Operating Temperature | -20°C to +60°C |
| Current Drain - idle (4.8V) | 8mA |
| Current Drain - idle (6.0V) | 8.8mA |
| Current Drain - no-load (4.8V) | 150mA |
| Current Drain - no-load (6V) | 180mA |
| Continuous Rotation Modifiable | Yes |
| Direction w/ Increasing PWM Signal | Clockwise |
| Deadband Width | 8µs |
| Motor Type | 3 Pole Ferrite |
| Feedback Style | 5KΩ Potentiometer |
| Output Shaft Support | Dual Ball Bearings |
| Gear Material | Nylon |
| Wire Length | 11.81" (300mm) |
| Weight | 1.6oz (45.5g) |
| Wire Gauge | 25AWG |
| Direction | Clockwise (stock) |
| Servo Size | Standard |
