1/2" Bore, Face Thru-Hole Pillow Block - Wide

SKU: Build System: Actobotics
$7.99

This ½" bore pillow block was designed for use in the Large Size ServoBlocks™. It’s great for one-off projects where you’re not constrained by a predetermined pattern and you need the extra span in one direction. Otherwise, check out the standard ½" Face Thru-Hole Pillow Block.

Downloads

Specs

Material Aluminum Housing, High-Carbon Steel Bearing
Weight 0.28 oz (8.0g)
Static Load 114 lbs
Max RPM 24,000
Bearing ID 0.500"
Dynamic Load 200 lbs
