1310 Series Hyper Hub (4 Start, 8mm Lead Screw Bore)
SKU:
Build System: goBILDA
This Hyper Hub has a threaded bore to match our 8mm lead screws. Being able to clamp tightly around a lead screw gives you the ability to put a gear, sprocket or pulley onto a lead screw in order to rotate it to create a linear motion assembly. The lead screw bore provides additional holding power that is sometimes needed to take the immense forces a lead screw can put on a hub.
Features
Made for 8mm Lead Screws
This hub allows you to mount components to an 8mm lead screw.
Part of a Large Ecosystem of Parts
The goBILDA® ecosystem has many parts that bolt directly to this hub. That includes gears, sprockets, timing pulleys, round belt pulleys, and more!
High-Speed Design - Completely Balanced
The innovative Hyper Hub design is perfectly balanced. It will not introduce vibrations into your build, even in high-speed applications.
High-Torque Design
The generous amount of shaft contact paired with the positive drive provided by the 8mm lead screw bore allows this hub to be used in high-torque applications.
Will Not Get Stuck or Marr Shaft
Our Hyper Hub design (patents pending) holds incredibly tight to the shaft without damaging it. When it is time to disassemble, it readily releases its grip on the shaft.
Precisely Machined
This hub is machined for high-precision fitment.
Will Not Corrode or Rust
The body of this hub is aluminum, and the pinch bolts are zinc-plated steel.
Lightweight & Strong
Aluminum has an excellent strength-to-weight ratio, allowing this hub to be both light and strong.
Downloads
Specs
| Weight | 23g |
|---|---|
| Material | Aluminum |
| Finish | Clear Anodized |
| IP | Patents Pending |
