2302 Series Aluminum, MOD 0.8, Hub Mount Gear (32mm Bore, 90 Tooth)

SKU: Build System: goBILDA

The 90 tooth, MOD 0.8 gear will mate with any MOD 0.8 gear, but when building on pattern, the most common partner for this gear is a 30 tooth pinion gear or servo gear.  Using the pinion gear you can create 3:1 underdrive or overdrive setup depending on your application.  When used with the 30 tooth servo gear, the combo creates a 3:1 underdrive, slowing the final speed while increasing the torque by 3x.



Weight 28g
Material Aluminum
Finish Clear Anodized
Tooth Count 90
Gear Pitch MOD 0.8
Pressure Angle 20 Degree
