25 RPM Econ Gear Motor

SKU:
$14.99

Tech Tip

Stalling this gearmotor could cause gear damage.

Specs

Output Shaft Style D-shaft
Motor Type Brushed DC
Output Shaft Support Bushing
Gear Material Metal
Weight 3.32 oz (91g)
Voltage (Nominal) 12V
Speed (No Load @ 12VDC) 25 rpm
Current (No Load @ 12VDC) 0.12A
Current (Stall @ 12VDC) 3.9A
Torque (Stall @ 12VDC) 2,034 oz-in (146.43 kgf-cm)
Gearbox Style Straight Cut Spur
Connector Type Male Spade Terminal
Gear Ratio 378:1
