4900 RPM Micro Gear Motor

  • Shown with a 3mm to 1/4” set screw shaft coupler
  • The 3mm bore hub is great for attaching other components
  • Use with our 3mm bore pinion gears
  • Use our quick connect power input board (#605112) with this motor
  • Shown on a quarter for scale
1 of 6

Be the first to review this product

Part
638138
638138
Status
In stock
This Product? Share It!
SPECS

Stalling this gear motor could cause gear damage.

*At Nominal Voltage

Voltage (Nominal) 12V
Voltage Range (Recommended) 6V - 12V
Current (No Load)* 120mA
Current (Stall)* 1600mA
Torque (Stall)* 2 oz-in
Gear Ratio 5:1
Gear Material Metal
Gearbox Style Straight Cut Spur
Motor Type DC
Output Shaft Diameter 3mm (0.118")
Output Shaft Style D-shaft
Output Shaft Support Brass Case
Electrical Connection Male Spade Terminal
Mounting Screw Size M1.6 x 0.35mm
Product Weight 0.3 oz (8.5g)
