HS-5565MH Servo

The HS-5565MH Servo features a high performance coreless motor, heavy-duty metal gears, and dual ball bearings, and is rated for 7.4 volt, 2S LiPo operation. The HS-5565MH brings lightning speed and acceleration to your 1/10th scale touring cars, buggies, and short course vehicles, helicopters up to .90-size, and sport to high performance aircraft up to 25 percent.

How Far Will This Servo Rotate?

The answer to this question is partially dependant on what you are using to control the servo.
Click for a quick video explanation.

Stock:

With an Average Radio System:
71°
Your average transmitter and receiver will output a relativly narrow PWM signal range.

Radio System + Servo Stretcher:
119°
Adding a Servo Stretcher to your radio system setup will allow you to achieve wide PWM signal ranges.

Wide Signal Controllers:
119°
Controllers such as the Actobotics® Servo Controller, Arduinos, and Raspberry Pi servo hats can usually send a wide signal.

Reprogrammed:

Whether you purchase the reprogrammed option or get a servo programmer and do it yourself, a reprogrammed version of this servo will be able to achieve greater travel than it can in stock form.

With an Average Radio System:
120°
Your average transmitter and receiver will output a relativly narrow PWM signal range.

Radio System + Servo Stretcher:
200°
Adding a Servo Stretcher to your radio system setup will allow you to achieve wide PWM signal ranges.

Wide Signal Controllers:
200°
Controllers such as the Actobotics® Servo Controller, Arduinos, and Raspberry Pi servo hats can usually send a wide signal.

Features

  • Rated for 2S LiPo operation
  • Ideal for 1/10 scale touring cars, buggies and short course vehicles, helicopters up to .90 size, and sport to high performance aircraft up to 25%
  • Heavy duty metal gears and dual ball bearings
  • Coreless motor
  • Two year limited warranty through Hitec beginning at date of purchase

Tech Tips

Specs

Output Shaft Style C24T Spline
Voltage Range 6.0V - 7.4V
No-Load Speed (7.4V) 0.09sec/60°
No-Load Speed (6.0V) 0.11sec/60°
Stall Torque (6.0V) 153 oz-in (11 kg.cm)
Stall Torque (7.4V) 194 oz-in (14 kg.cm)
Max PWM Signal Range 750-2250μsec
Travel per µs (Stock) .079°/μsec
Travel per µs (Reprogrammed) .134°/μsec
Max Rotation (Stock) 119°
Max Rotation (Reprogrammed) 200°
Pulse Amplitude 3-5V
Operating Temperature -20°C to +60°C
Continuous Rotation Modifiable Yes
Direction w/ Increasing PWM Signal Clockwise
Deadband Width 2µs
Motor Type Coreless
Feedback Style 5KΩ Potentiometer
Output Shaft Support Dual Ball Bearings
Gear Material Metal
Wire Length 11.81" (300mm)
Weight 2.10oz (60g)
Wire Gauge 22AWG
Servo Size Standard
