3.5mm Bullet Lead (MH-FC, 300mm Length)

1 of 4

Be the first to review this product

Part
3800-0013-0300
3800-0013-0300
Status
In stock
This Product? Share It!

Details

This bullet lead consists of 300mm of 16AWG, bonded wire that is terminated in 3.5mm (MH-FC) bullet connectors on one end and bare wires on the other.  The bare wires are great for going into screw terminals of a motor controller, soldering into thru-holes of a PCB or for soldering up a custom wiring harness.  The bullet connectors on this lead are directly compatible with the goBILDA 5201 Series and 5202 Series gear motors and are an excellent choice for high-current applications that are space limited. Bullet connections also give you the freedom to reverse polarity easily by switching the connections.

SPECS

3.5mm Bullet Lead (MH-FC, 300mm Length)

Product Weight 0.53oz (15g)
Wire Gauge 16AWG
Wire Insulation Material PVC
Connector Type SH3.5 Bullet
Gender MH-FC (Male Housing, Female Contact)
