34 RPM Econ Gear Motor


Currently Sold Out

Tech Tip

Stalling this gearmotor could cause gear damage.


Output Shaft Style D-shaft
Motor Type Brushed DC
Output Shaft Support Bushing
Gear Material Metal
Weight 3.32 oz (91g)
Voltage (Nominal) 12V
Speed (No Load @ 12VDC) 34 rpm
Current (No Load @ 12VDC) 0.11A
Current (Stall @ 12VDC) 3.85A
Torque (Stall @ 12VDC) 1,530 oz-in (110.20 kgf-cm)
Gearbox Style Straight Cut Spur
Connector Type Male Spade Terminal
Gear Ratio 286:1
