Gear-Driven Turret (2.75:1 Ratio, 105mm ID)
SKU:
This Gear-Driven Turret lets your robot rotate a shooting mechanism smoothly and precisely without having to turn the whole chassis. The 105mm bore provides a clear path for elements to feed up through the center, and a large steel ball bearing seated in a precision-machined aluminum housing keeps rotation smooth and consistent so your aim stays true.
Mounting
On-pattern holes on its sides make it straightforward to fasten the turret to your robot's structure, and the top follows the goBILDA® 8mm grid for whatever shooting mechanism you build above it. Whether you're fastening goBILDA® components or your own custom-machined or 3D-printed creations up top, this turret gives your shooting mechanism a firm foundation.
Drive
This Turret can be driven by a ServoBlock®, a Yellow Jacket Planetary Gear Motor, or an A301 actuator thanks to the included 1-Side, 2-Post Motor Mount. Both the mount and the 64-Tooth Hub-Mount Gear are also available individually, so you can add a second drive source for higher torque or redundancy.
Recommended Drive Configurations
All values reflect output at the turret after the 2.75:1 reduction.
| Setup | Turret Speed | Turret Torque |
|---|---|---|
| 1x Axon MINI Servo | 40.36 RPM | 954.25 oz-in |
| 2x Super Speed Servo | 83.63 RPM | 357.5 oz-in |
| 1x 312 RPM Yellow Jacket | 113.45 RPM | 929.5 oz-in |
| 1x 435 RPM Yellow Jacket | 158.18 RPM | 715 oz-in |
Downloads
Specs
| Weight | 438g Assembled (Includes 64T Gear) |
|---|---|
| Material | Aluminum Housing, High-Carbon Steel Bearing |
| Included M4 Screws | Socket Head: |
