Weight | 1.1oz |
---|---|
Stroke | 1.2" |
Gear Ratio | 210:1 |
Voltage Range | 4.8 - 7.4VDC |
Operating Temperature | -10°c ~ +50°c |
Motor Type | Brushed DC |
Feedback Style | Digital |
Wire Length | 6.3" |
Connector Type | 3-Pos TJC8 Servo Connector [MH-FC] |
Manufacturer Part Number | 41005 |
Max PWM Range | 1050-1950μsec |
Speed (No Load) @ 6VDC | 6.1mm/sec | 0.2"/sec |
Speed (No Load) @ 7.4VDC | 7.5mm/sec | 0.3"/sec |
Thrust @ 6VDC | 10.0kg | 22.0lb |
Thrust @ 7.4VDC | 12.4kg | 27.3lbs |
Current Drain (Stall) @ 6VDC | 500 mA |
Current Drain (Stall) @ 7.4VDC | 620 mA |
